High Vacuum Glass Stopcock Design


Stopcocks are an integral component of laboratory glassware such as burettes, separatory funnels, Schlenk flasks, and columns used in column chromatography – they’re even found in some vacuum systems! Obtain the Best information about Fineo vacuum glazing.

Glass makes an ideal material for high vacuum devices because its expansion and contraction rates remain consistent across various temperatures, an attribute that is especially crucial in applications involving high vacuum.

Optimal Valve Design

The design of high vacuum glass stopcocks should consider your application requirements. One key parameter is saturated vapor pressure – vacuum greases typically have an atmospheric saturation level below 10-4 Pa at room temperature and 130degC.

System pressure range and fluidic media play an essential role, as they will determine the torque necessary to rotate a valve stem (open/close it).

PTFE stopcocks do not require lubrication to work effectively at temperatures ranging from -40 to 200degC; however, for best performance at these temperatures, a thin layer of vacuum grease should be applied evenly to both halves of the valve to prevent premature wear and corrosion. It has low vapor pressure while remaining resistant to attacks by acidic and alkaline solutions – ideal for protecting ground glass joints, glass stopcock, valves, Tensette Pipets, and desiccators from acid attacks!

Optimal Plug Design

A proper design for high vacuum glass stopcocks requires only minimal considerations: It must align with the hole on the barrel. Otherwise, mismatches could leak or jam. In addition, precision grinding would ensure the plug fits perfectly with its barrel’s hole.

Another consideration when installing plugs is whether or not the pin is lubricated. Without adequate lubrication, its loosening could result in dirt collecting on it and entering the hole (see Fig 32).

Dirt can cause wear-and-tear damage to the barrel’s interior. It wears grooves along its walls that eventually line up with arms on either side, allowing the material to enter your chamber unimpeded.

Preventing corrosion with regular cleaning is the best way to protect freshmen chemistry burettes against potential long-term damage. Regular rinsing of burettes can make an immense difference in long-term performance and health.

Optimal Barrel Design

Several key features should be considered when selecting a high vacuum glass stopcock design. One is taper design. In an ideal scenario, its barrel should have a 1:5 taper ratio.

Another critical consideration in stopcock and plug production is their final grind. While other joint parts may only receive grinding after assembly, stopcocks and their joints must be lapped before fitting together.

Final grinding ensures the two parts can move without colliding with one another when rotated, thereby avoiding cross-matched plugs and barrels leaking or jamming during rotation.

Before using vacuum equipment, it is a wise idea to make sure it has the appropriate plug size and size. Furthermore, do not mix stopcocks or joints with different sizes of plugs together.

Optimal Grease Design

Stopcocks regulate, interrupt, and entirely stop the flow of liquids and gases through pipes or tubes. They may be held securely by a vacuum, rubber rings, or clips.

Glass stopcocks feature plugs made of metals such as brass, aluminum, stainless steel, or tin that are sealed using grease to prevent air leakage between the shell and plug. While these stopcocks work effectively for low vacuum applications, they may not perform as well at handling higher vacuum.

Another stopcock option is a hybrid design that utilizes an O-ring seal at the joint and socket seal to form an airtight seal between the plug and shell. However, this design must be grounded to not interfere with the O-ring vacuum sealing capability.

Fluorinated greases such as Krytox (registered and manufactured by Du Pont) can provide the answer. However, there are various other fluorinated greases on the market as well.
